• Terminal Body: Copper (端子材質: 紫銅)
    • Plating: Tin(表面處理: 鍍錫)

Please Click products below, and click Add to Inquiry List for inquiry.
Wire Range mm2/Awg 適用電線 Dimension主要尺寸 L Dimension主要尺寸 D Dimension主要尺寸 C Dimension主要尺寸 W Q’TY BOX 包裝量
inch mm inch mm inch mm inch mm

CN005006



0.5(22)
6.0 .236 1.3 .051 1.0 .038 2.1 .083 1000

CN005008

0.5(22)
8.0 .315 1.3 .051 1.0 .038 2.1 .083 1000

CN005010

0.5(22)
10.0 .394 1.3 .051 1.0 .038 2.1 .083 1000

CN007506

0.75(20)
6.0 .236 1.5 .059 1.2 .047 2.3 .091
1000

CN007508

0.75(20)
8.0 .315 1.5 .059 1.2 .047 2.3 .091
1000

CN007510

0.75(20)
10.0 .394 1.5 .059 1.2 .047 2.3 .091
1000

CN010006

1.0(18)
6.0 .236 1.7 .067 1.4 .055 2.5 .098
1000

CN010008

1.0(18)
8.0 .315 1.7 .067 1.4 .055 2.5 .098
1000

CN010010

1.0(18)
10.0 .394 1.7 .067 1.4 .055 2.5 .098
1000

CN010012

1.0(18)
12.0 .472 1.7 .067 1.4 .055 2.5 .098
1000

CN015007

1.5(16)
7.0 .276 2.0 .079 1.7 .067 2.8 .110
1000

CN015008

1.5(16)
8.0 .315 2.0 .079 1.7 .067 2.8 .110
1000

CN015010

1.5(16)
10.0 .394 2.0 .079 1.7 .067 2.8 .110
1000

CN015012

1.5(16)
12.0 .472 2.0 .079 1.7 .067 2.8 .110
1000

CN025007

2.5(14)
7.0 .276 2.5 .098 2.2 .087 3.4 .134
1000

CN025008

2.5(14)
8.0 .315 2.5 .098 2.2 .087 3.4 .134
1000

CN025010

2.5(14)
10.0 .394 2.5 .098 2.2 .087 3.4 .134
1000

CN025012

2.5(14)
12.0 .472 2.5 .098 2.2 .087 3.4 .134
1000

CN040008

4.0(12)
8.0 .315 3.2 .126 2.8 .110 4.0 .157
1000

CN040009

4.0(12)
9.0 .354 3.2 .126 2.8 .110 4.0 .157
1000

CN040010

4.0(12)
10.0 .394 3.2 .126 2.8 .110 4.0 .157
1000

CN040012

4.0(12)
12.0 .472 3.2 .126 2.8 .110 4.0 .157
1000

CN040015

4.0(12)
15.0 .591 3.2 .126 2.8 .110 4.0 .157
1000

CN040018

4.0(12)
18.0 .709 3.2 .126 2.8 .110 4.0 .157
1000

CN060010

6.0(10)
10.0 .394 3.9 .154 3.5 .138 4.7 .185
1000

CN060012

6.0(10)
12.0 .472 3.9 .154 3.5 .138 4.7 .185
1000

CN060015

6.0(10)
15.0 .591 3.9 .154 3.5 .138 4.7 .185
1000

CN060018

6.0(10)
18.0 .709 3.9 .154 3.5 .138 4.7 .185
1000

CN100012

10.0(8)
12.0 .472 4.9 .193 4.5 .177 5.8 .228
1000

CN100015

10.0(8)
15.0 .591 4.9 .193 4.5 .177 5.8 .228
1000

CN100018

10.0(8)
18.0 .709 4.9 .193 4.5 .177 5.8 .228
1000

CN160012

16.0(6)
12.0 .472 6.2 .244 5.8 .288 7.5 .285
1000

CN160015

16.0(6)
15.0 .591 6.2 .244 5.8 .288 7.5 .285
1000

CN160018

16.0(6)
18.0 .709 6.2 .244 5.8 .288 7.5 .285
1000

CN250015

25.0(4)
15.0 .591 7.7 .303 7.3 .287 9.5 .374
500

CN250016

25.0(4)
16.0 .630 7.7 .303 7.3 .287 9.5 .374
500

CN250018

25.0(4)
18.0 .709 7.7 .303 7.3 .287 9.5 .374
500

CN250022

25.0(4)
22.0 .866 7.7 .303 7.3 .287 9.5 .374
500

CN350016

35.0(2)
16.0 .630 8.7 .343 8.3 .327 11.0 .433
500

CN350018

35.0(2)
19.0 .709 8.7 .343 8.3 .327 11.0 .433
500

CN350020

35.0(2)
20.0 .787 8.7 .343 8.3 .327 11.0 .433
500

CN350025

35.0(2)
25.0 .984 8.7 .343 8.3 .327 11.0 .433
500

CN500018

50.0(1/0)
19.0 .709 10.9 .429 10.3 .406 13.0 .511
250

CN500020

50.0(1/0)
20.0 .787 10.9 .429 10.3 .406 13.0 .511
250

CN500025

50.0(1/0)
25.0 .984 10.9 .429 10.3 .406 13.0 .511
250

CN700022

70.0(2/0)
22.0 .866 14.3 .563 13.5 .531 15.3 .602
250

CN700025

70.0(2/0)
25.0 .984 14.3 .563 13.5 .531 15.3 .602
250

CN950025

95.0(3/0)
25.0 .984 15.5 .610 14.7 .579 16.6 654
250

CN950032

95.0 (3/0)
32.0 1.260 15.5 .610 14.7 .579 16.6 654
250

CN120030

120.0(4/0)
30.0 1.181 17.6 .693 16.7 .657 18.6 .732
100

CN120032

120.0(4/0)
32.0 1.260 17.6 .693 16.7 .657 18.6 .732
100

CN120034

120.0(4/0)
34.0 1.339 17.6 .693 16.7 .657 18.6 .732
100

CN150032

150.0(250/300MCM)
32.0 1.260 20.5 .807 19.5 .768 21.5 .846
100

CN150038

150.0(250/300MCM)
38.0 1.496 20.5 .807 19.5 .768 21.5 .846
100
